Keller minimal windows® KELLER minimal windows® curve Curved aluminium window

ADD TO WISHLIST OR PROJECT
Overview

KELLER minimal windows® curve By Keller minimal windows®

Type

Curved aluminium window

Manufacture year

2023

Keller minimal windows® curve creates flowing contours and fine transitions without having to do without the desired transparency.‎ The curved minimal windows® sliding elements offer maximum flexibility in the implementation of architectural ideas, even with large dimensions.‎ The curved glazing is smooth running and easy to move.‎ The requirements for thermal and sun protection can be combined perfectly with minimal windows® curve.‎

TECHNICAL CHARACTERISTICS
• Min.‎ radius: > 4000 mm for sliding leaves > 1500 mm for fixed leaves
• Maximum leaf height: 4500 mm
• Max.‎ leaf width: dependent on radius
• Maximum sliding leaf weight: 500 kg for double glazing, 1000 kg for triple glazing
• Only manual operation possible
• Only powder coating possible

THE ADVANTAGES
• Timeless, reduced design - visually delicate
• Flexible integration in both minimal windows® series
• Large, curved fixed and sliding leaves
• Transition without threshold
• Different surface designs
• Drainage integrated in the system
• Modular system structure
• High flexibility and user comfort

Further info from manufacturer on KELLER minimal windows® curve Keller minimal windows®
Read more
Dimensions

Min. radius for sliding leaves 4,000 mm
Min. radius for fixed leaves 1,000 mm
Maximum leaf height 4,5 m
Maximum leaf width: dependent on radius
