PORTAPIVOT 4245 - SINGLE DOOR By Portapivot
Pivot door system made from high quality anodized aluminium available in 3 decorative finishes, black, silver and bronze. The spaceframe structure can be fitted with various finishes such as MDF, glass, Corian, Trespa, ceramics,….
Portapivot 4245 is sold as a made to measure self-assembly kit, designed for interior professionals and craftsmen. The self-assembly kit consists of the aluminium 4245 frame, a Stealthpivot set and all the necessary assembly and installation accessories.
Portapivot’s door systems are equipped with Stealthpivot invisible pivot hinges, which feature a high-tech comfort closure, that works in all swing directions. The pivot hinge can be configured for 180° or 360° operation.
The pivot hinge is mounted on top of the finished floor and a solid or reinforced ceiling surface, without any pre-installed fixtures. The minimal anchoring (2 bolts +-4.5 cm deep) allows for easy installation on any type of solid surface.
Dimensions:
Minimum height: 1800 mm
Maximum height: 2975 mm
Minimum width: 500 mm
Maximum width: 2250mm
Portapivot 5730 kit
Made to measure aluminium frame 42 x 45 mm
Stealthpivot hinge set
Assembly accessories
Stealthpivot
Compact size
Modular axis point
Self-closing technology
-90° 0° +90° open/hold positioning
Configurable swing operation: 180° or 360°
